SKU: OEPS-6571 (3D capable)
SKU: OEPS-6570 (Accelerometer)

The low profile greatly reduces torque, minimizing the impact of the headstage on animals. Mice can lower their heads and are free to perform most behaviours, such as licking/nosepoke paradigms.

Compatible with the ShuttleDrive and the ShuttleDrive 64-ch Hirose EIB, though its low weight and features make this headstage very appealing for a large spectrum of usage.

Key aspects:

• 0.92 g (0.46 g lighter than 64ch vertical-profile Omnetics-based headstages)

• Exclusive 9-axis inertial measurement unit (IMU) allowing autonomous drive of the torque-free SPI commutator.

• Compatible with the Open Ephys Acquisition Board and all Intan Rhythm systems

• Includes 2 infrared LEDs for tracking purposes

• Flat, round, low-torque design

Available variants:

• OEPS-6571 - 64 channel headstage with full 3D capabilities (9-axis IMU) for head positioning recording and the ability to autonomously drive the torque-free SPI commutator.

• OEPS-6570 - 64 channels headstage with a 3-axis accelerometer. No 3D capabilities.

Package includes:

• 1 Low-Profile SPI Headstage 64ch of the variant you choose.

Notes:

• The 3D capabilities require an Open Ephys Acquisition Board (3rd Generation) to work.

• The 3D capabilities can’t be used when operating the headstage combined with a dual headstage adapter.

• The ground and reference connections are different depending on the version of the device:

• Version 1.0 - Not connected

• Version 1.1 and onwards - Tied together
